Product Name :PB Series Plastic Enclosure junction box(Metal Screw)
Model :PB-AG,PB-AT,PB-PG,PB-PT
Material : ABS,Plastic
Colour : Light Gray or Customize
Application : Electrical or industrial
Processing : Plastic Injection
Customization : Cutout holes, silkscreen print etc
Drawing Format :PDF, CAD, STP, Jpg etc
Function : Water-proof, Dust-proof, Fire-proof, Ultraviolet-proof
Protection Level:Ip66
The PB series plastic housing junction box is made of high-quality plastic, with high hardness and durability. Equipped with screws for easy assembly. It has good performance, no corrosion, anti static, and insulation resistance. There are screw holes inside for PCB fixing. It can be used indoors and outdoors, suitable for various types of control boxes, cabinets, power distribution instrument boxes, electronic enclosures, etc.
| Size | Product model | Product model | Size | Product model |
Product model |
|---|---|---|---|---|---|
|
(widthxlengthx |
Cover:Grey ABS | Cover:Tranparent PC | (widthxlengthx | Cover:Grey ABS | Cover:Tranparent PC |
| depth mm) | Body:Grey ABS | Body:Grey ABS | depth mm) | Body:Grey ABS | Body:Grey ABS |
| 120 x200 x75 | PB-NG-122007 | PB-NT-122007 | 260x380 x70 | PB-NG-263807 | PB-NT- 263807 |
| 120 x 200 x113 | PB-NG-1 22011-H | PB-NT-122011 | 260x380x85 | PB-NG-263808 | PB-NT- 263808 |
| 1 20 x200 x 75 | PB-NG-122007-E | PB-NT-122007 | 260x 380x105 | PB-NG-263810 | PB-NT- 2638 10 |
| 1 20x200 x 56 | PB-NG -122005-L | PB-NT-122005 | 260x 380x120 | PB-NG-263812-M | PB-NT-263812-M |
| 120x20 0 x 67 | PB-NG-120206-E | PB-NT-120206 | 260x 380x140 | PB-NG- 263814-H | PB-NT-263814-H |
| 90 x158 x 60 | PB-NG-091506 | PB-NT-091506 | 81 x120 x65 | PB-NG-081206-E | PB-NT-0812 06 |
| 90 x 158 x64 | PB-NG-091506-E | PB-NT-091506 | 120x120x90 | PB-NG-121209 | PB-NT-121209 |
| 90 x158 x40 | PB-NG-09 1504-L | PB-NT-091504 | 150x230 x8 5 | PB-NG- 152308 | PB-NT- 152308 |
| 90 x115 x 55 | PB-NG-091105 | PB-NT-091105 | 150x230 x87 | PB-NG-152308- F | PB-NT-1 52308 |
| 90 x11Sx SS | PB-NG-091105-E | PB-NT-091105 | 150x230 x87 | PB-NG-152308-E | PB-NT-152308 |
| 90 x115 x68 | PB-NG-091106- E | PB-NT-091106 | 45x160x55 | PB-NG-041605 | PB-NT-041605 |
| 68 x100 x 50 | PB-NG-061005 | PB-NT-061005 | 58x83x33 | PB-NG-050803 | PB-NT-0 50803 |
| 68 x 100 x40 | PB-NG -061004-E | PB-NT-06 1004 | 58x83x33 | PB-NG-050803-E | PB-NT-050803 |
| 68 x100x 50 | PB-NG-061005-E | PB-NT-061005 | 58x63 x35 | PB-NG-050603 | PB-NT-050603 |
| 160 x 160 x70 | PB-NG-16 1607-L | PB-NT -161607 | 58x63 x35 | PB-NG-050603-E | PB-NT-050603 |
| 1 60x 160 x 90 | PB-NG-161609 | PB-NT-161609 | 160x240 x90 | PB-NG-162409 | PB-NT-162409 |
| 160 x 160 x 90 | PB-NG-161609 | PB-NT-161609 | 160 x240 x 120 | PB-NG -161412-H | PB-NT-161412 |
| 182 x263 x 95 | PB-NG-182609 | PB-NT-182609 | 110 x160x90 | PB-NG-111610 | PB-NT-111610 |
| 182 x263 x 60 | PB-NG-182606-L | PB-NT-182606 -L | 188 x192x100 | PB-NG-181910 | PB-NT-181910 |
| 182 x 263 X 125 | PB-NG-1826 12 -H | PB-NT-182612 | 188 x192x100 | PB-NG-181910-E | PB-NT-181910 |
| 90 x 158 x46 | PB-NG-091504 | PB-NT-091504 | 81 x83 x 56 | PB-NG-080805 | PB-NT-080805 |
| 90 x 158 x 60 | PB- NG-091506 -H | PB-NT-091506 | 210 x290 x60 | PB-NG-212906 | PB-NT- 212906 |
| 85 x115 x 35 | PB-NG-081103-E | PB-NT-081103 | 21O x290 x100 | PB-NG-212910 | PB-NT-212910 |
| 195 x280 x 135 | PB-NG-192813 | PB-NT-192813 | 280X 300X 140 | PB-NG-283014 | PB-NT- 283014 |
| 195 x280 x86 | PB-NG -192808- L | PB-NT-192808 | 290 x390 x 165 | PB-NG- 293916-W | PB-NT- 293916 |
| 240x 320 x 60 | PB-NG -243206- L | PB-NT-243206-L | 290x390 x 166 | PB-NG-293916 | PB-NT- 293916 |
| 240x 320x 110 | PB-NG-243211 | PB-NT-243211 | 170x2 50 x120 | PB-NG-172512 | PB-NT-172512 |
| 240 x320 x140 | PB- NG- 2432 14 -H | PB-NT-243214 | 100 x125x 52 | PB-NG-101205 | PB-NT-101205 |
| 240 x 320 x 155 | PB- NG -243215 - H | PB-NT-243215 | 270 x300 x 112 | PB-NG-273011 | PB-NT- 273011 |
