Waterproof DC 4P 32A Disconnector isolator switch

Technical Parameters

Solar Isolator Switch
Rated Current
Number Of Poles
Rated Voltage

Product Description:
Waterproof IP66 Solar DC 1500V 32A PV Photovoltaic Isolator Isolating Switch with.
Safety design:
We offer a comprehensicve range of isolating switches designed with safety in mind this switch are padlockable.
1.Compact and suitable where space is limited.
2.Load-breaking up to 8 times rated current making it ideal for motor isolation.
3.Double-break with silver rivets-superior performancereliability and long lasting.
4.Padlockable handle-tamper-proof.
5.Highly visible red handle.

Pole 4
Rated voltage DC1000V-DC1200V
Rated current 10A/16A/20A/25A/32A
Working temp  -25C~85C
Dimensions 110X120X210mm
Waterproof degree IP66
Standards IEC60947-3
Insulated voltage DC 1500V
Single weight 750g
